Agilent 1200 HPLC G1367B High Performance Autosampler
Injection Range
0.1 – 100 µl in 0.1 µl increments
Precision
Typically < 0.25 % RSD from 5 – 100 µl
Typically < 1 % RSD from 1 – 5 µl
Pressure Range
400 bar (5800 psi)
- Overlapped injections maximize productivity by reducing cycle times between runs
- Minimal delay volumes enable rapid gradients and fast system equilibration after sample injection
- Flexible sample handling supports various container types, including well plates, vials, and Eppendorf tubes
- Advanced GLP features include early maintenance feedback (EMF) and electronic records of maintenance and errors
- Multiple communication options with CAN, RS232C, APG remote, and optional external contact closures for seamless integration
- Built-in safety features like leak detection, safe leak handling, and low voltages in maintenance areas ensure operational safety
- Fast injection cycle time of under 30 seconds for high-throughput workflows
- Exceptional carry-over reduction, typically < 0.01%, for cleaner and more accurate results
The Agilent 1200 HPLC G1367B High Performance Autosampler adds maximum flexibility and fast injection cycles to your Agilent HPLC system. Whenever high sample throughput and speed of analysis are points to consider, the G1367B is the autosampler to choose. Featuring a standard injection range from 0.1 to 100 μl, the G1367B Autosampler provides increased sample injection speed for high sample throughput. Other features include: overlapped injections for increased productivity, minimal delay volumes for rapid gradients and fast equilibration when bypassing the autosampler after sample injection, flexible and convenient sample handling with different types of sample containers.
All of our equipment is fully tested to perform at factory specifications before being shipped.
The Agilent 1200 HPLC G1367B High Performance Autosampler includes:
- > Firmware Version 07.02 (Can be changed upon request)
- > Vial Tray
- > Lab Advisor Documentation
- > Lan Cable / Power Cord
- > Operator's Manual
- > Full 180 Day Parts and Labor Warranty
Agilent 1200 HPLC G1367B High Performance Autosampler Specifications
|
GLP Features |
Early maintainece feedback (EMF), electronic records of maintainence and errors |
|
Communications |
Controller-area network (CAN). RS232C, APG remote standard, optional four external contact closures and BCD vial number output |
|
Safety Features |
Leak detection and safe leak handling, low voltages in maintence areas, error detection and display |
|
Injection Range |
0.1 – 100 µl in 0.1 µl increments Up to 1500 µl with multiple draw (hardware modification required) |
|
Precision |
Typically < 0.25 % RSD from 5 – 100 µl, Typically < 1 % RSD from 1 – 5 µl |
|
Pressure Range |
400 bar (5800 psi) |
|
Sample Viscosity Range |
0.2 – 5 cp |
|
Sample Capacity |
2 × well-plates (MTP) + 10 × 2 ml vials 108 x 2 ml vials in 2 x 54 vial plate plus 10 additional 2 mL vials 30 x 6-mL vials in 2 x 15 vial plate plus 10 additional 2 mL vials 54 Eppendorf tubes (0.5/1.5/2.0mL) in 2 x 27 Eppendorf tube plate |
|
Injection Cycle Time |
Typically < 30 s using following standard conditions: Default draw speed: 200 µl/min Default eject speed: 200 µl/min Injection volume: 5 µl |
|
Carry-Over |
Typically < 0.01 % using the following conditions: Column: 125 x 4 mm Hypersil ODS, 5 µm Mobile phase: Water/Acetonitrile = 80/20 Flow rate: 1 ml/min Injection volume: 1 µl caffeine (1 mg/ml), 5 µl water to test carryover Outside wash of needle before injection: 20 sec with water using flush port |
Click Here to View the Technical Specs for the G1367B Autosampler
