MJ Research PTC-150 Thermal Cycler
Thermal Range
-9 to 105C
Accuracy
± 0.3C of programmed target at 90C, NIST traceable
Sample Capacity
16-well block: 16 x 0.5mL tubes
25-well block: 25 x 0.2mL tubes or one 25-well microplate
- Instant Incubate feature for continuous-temperature incubations
- Easy-to-read programming interface for quick and efficient programming
- Hot Bonnet heated lid eliminates the need for oil overlays
- Advanced thermal homogeneity ensures minimal temperature variation between wells
- Nonvolatile memory storage for up to 80 programs with a total of 400 programmable steps
- 25-pin parallel interface port allows for external printer connectivity
All of our equipment is fully tested to perform at factory specifications before being shipped.
The MJ Research PTC-150 Thermal Cycler includes:
- > Power Cord
- > NIST Traceable Calibration Certificate
- > Operator's Guide
- > Full 180 Day Parts and Labor Warranty
MJ Research PTC-150 Thermal Cycler Specifications
|
Thermal Range |
-9 to 105C (no more than 35 below ambient temperature) |
|
Accuracy |
0.3C of programmed target at 90C, NIST traceable |
|
Thermal Homogeneity |
0.4C well-to-well within 12 seconds of arrival at 90C 0.3C well-to-well within 40 seconds of arrival at 90C |
|
Sample Capacity |
16-well block: 16 x 0.5mL tubes 25-well block: 25 x 0.2mL tubes or one 25-well microplate |
|
Ports |
One 25-pin 8-bit parallel interface printer port |
|
Memory |
80 typical programs, in nonvolatile memory each program may have up to 100 steps; maximum of 400 steps among all programs |
- Validate that the power supply and PCB consistently deliver accurate, stable voltages across all circuits and connections, confirming operational reliability
- Thoroughly inspect the display for any dim, flickering, or dead pixels, replacing compromised segments to ensure clear visibility and precise data display
- Verify complete functionality and responsiveness of all buttons and knobs, confirming accurate and reliable input across all controls
- Ensure the machine completes all internal diagnostic checks with zero errors, indicating system readiness and functional integrity
- Confirm the machine accurately identifies attached blocks (96-well, dual 48, etc.), with seamless recognition across different configurations
- Conduct a detailed inspection of internal wiring and all electrical connections, checking for any signs of breaks, disconnections, or tears; replace or repair any underperforming components
- Examine the connector between the block and base for bent or broken pins, replacing as needed to maintain secure, reliable connections
- Calibrate well temperatures with a NIST-traceable thermometer, verifying accuracy and uniformity across all wells to meet specification standards
- Perform a comprehensive cosmetic inspection, ensuring all exterior surfaces and components are free of damage, wear, or defects, maintaining aesthetic and professional quality
Technician Inspection and Recertification Checklist: Thermal Cycler
The Following Checklist Is to Be Performed on All Incoming and Outgoing Pieces of Equipment| Task | Completed? | Remarks? |
| Validate stable, accurate voltage outputs from power supply and PCB across circuits | Completed | |
| Inspect display for dim, flickering, or dead pixels; replace as needed for clarity | Completed | |
| Verify functionality and responsiveness of all buttons and knobs | Completed | |
| Confirm machine completes internal diagnostics with zero errors | Completed | |
| Ensure accurate block identification across configurations (96-well, dual 48, etc.) | Completed | |
| Inspect internal wiring and connections for integrity; repair or replace as needed | Completed | |
| Check connector between block and base for bent or broken pins; replace as necessary | Completed | |
| Calibrate well temperatures with a NIST-traceable thermometer for accuracy | Completed | |
| Conduct cosmetic inspection to ensure quality and professionalism of all surfaces | Completed |
